SEASONIC zdroj 1300W PRIME PX-1300, 80+ PLATINUM
PRIME PX-1300
Pressing on with its One Seasonic Initiative, the PRIME TX, PRIME PX and PRIME GX series became the successors to the Seasonic PRIME and PRIME Ultra series.
The PRIME Series has always demonstrated outstanding performance and have become the epitome of technological excellence and quality through the years. This third generation of PRIME Series rolled out not only with a uniformed naming scheme but also with updated general design and connection cables. As each new model in these PRIME series have their distinctive set of features and specifications, prospective customers will find a streamlined buying guidance through understanding the One Seasonic process.
- 80 PLUS® Platinum certified
- Micro Tolerance Load Regulation (0.5 %)
- Cable-free Connection Design
- Premium Hybrid Fan Control - Fanless until 40 % load
- Multi-GPU setup
- Gold plated connectors
- 12 years warranty
TECHNICAL SPECIFICATIONS
80PLUS® | Platinum |
Cybenetics Efficiency Level | TBA |
Cybenetics Noise Level | TBA |
Form Factor | Intel ATX 12 V |
Dimensions (L x W x H) | 210 x 150 x 86 mm |
Fan Size | 135 mm |
Fan Control | Premium Hybrid Fan Control |
Fan Bearing | Fluid Dynamic Bearing |
Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH |
Modularity | Fully Modular |
Cable type | Flat black cables |
Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
MTBF @ 25 °C, excl. fan | 150,000 hours |
AC Input | Full Range |
Protection | OPP, OVP, UVP, OCP, OTP, SCP |
Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
Warranty | 12 Years |
AC Input | Voltage: 100 V - 240 V Current: 15 - 10 A Frequency: 50 Hz - 60 Hz |
.
ParametryPorovnání
Formát zdroje
ATX
Konektory
PCIe 8-pin
Konektory
Molex
Konektory
SATA 15-pin
Konektory pro základní desku
ATX 24-pin
Efektivita zdroje
80 Plus Platinum
